Khaled Stainless, located in Cairo, Egypt, provides a wide array of stainless steel angles tailored for architectural, structural, and fabrication purposes. Our L-sections are crafted from certified coil or billet, utilizing precision hot-rolling and cold-forming techniques. We offer both standard and custom leg lengths, thicknesses, and profiles—equal or unequal. Each batch undergoes thorough inspection for straightness, dimensional accuracy, and surface quality, and comes with mill test certificates for complete traceability. Finishes available include mill, pickled & passivated, brushed, and polished. Khaled Stainless is here to support contractors, fabricators, OEMs, and distributors with services like cut-to-length, CNC punching, welding prep, and customized packaging for both local and export projects.
Stainless steel angles come in various grades—most commonly 304/304L, 316/316L for chloride resistance, 430 for cost-effective ferritic needs, and duplex grades for enhanced strength. The typical austenitic grades (304/316) contain around 17–20% chromium and 8–14% nickel, with 316 featuring an additional 2–4% molybdenum. The mechanical properties of annealed austenitic angle stock generally show tensile strength between 515–690 MPa, yield strength around 205–310 MPa, and elongation greater than 40%; hardness usually falls between 150–200 HB. Duplex angles provide superior yield and tensile strengths. All materials are supplied with MTCs, and heat treatment or surface finishing can be arranged upon request.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Khaled Stainless, our stainless steel corners undergo rigorous testing to ensure quality and meet international standards. Certified for strength, durability and corrosion resistance, our products meet ISO and ASTM standards. Each batch is tested for chemical composition, mechanical properties and dimensional accuracy to ensure reliability and customer satisfaction.
Stainless steel angles are L-shaped structural components made from stainless steel. They provide strength and support for various applications, including construction, manufacturing, and architectural projects, offering durability and corrosion resistance.
Stainless steel equal angles have two legs of equal length, forming a 90-degree angle. They are used for structural support and reinforcement in construction, offering strength, durability, and corrosion resistance.
Stainless steel unequal angles have legs of different lengths, forming a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering strength, durability, and corrosion resistance.
Stainless steel L angles are L-shaped structural components used for framing and support. They offer strength, durability, and corrosion resistance, making them suitable for construction, manufacturing, and architectural applications.
SS T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are used in structural applications and frameworks, offering high strength, durability, and corrosion resistance.
Stainless steel corner angles are L-shaped sections designed for joining or reinforcing corners in construction and fabrication. They provide strong, durable, and corrosion-resistant support for various structural and architectural applications.
Stainless steel angles are incredibly versatile and find applications in construction, building façades, structural framing, handrails and balustrades, stair stringers, equipment supports, racks, and shelving. They are often specified in food processing, pharmaceutical, and chemical plants due to their corrosion resistance and hygiene properties, as well as in marine and offshore settings (using 316/duplex) where exposure to chlorides is a concern. Fabricators utilize them for welded assemblies, brackets, bases, and reinforcement in architectural metalwork. Khaled Stainless is committed to providing high-quality solutions for all your stainless steel angle needs.
